POA-LMP81 lamp replacement

When the life of the Projection POA-LMP81 Lamp of this projector draws to an end,

the POA-LMP81 LAMP REPLACE indicator lights yellow. If this indicator lights

yellow, replace the projection POA-LMP81 lamp with a new one promptly

Follow these steps to replace lamp assembly.

1    Turn off a projector and disconnect AC plug. Allow a projector to

      cool for at least 45 minutes

2    Loosen 2 screws with a screwdriver and open POA-LMP81 Lamp Cover

3    Loosen 2 screws with a screwdriver and pull out Lamp Assembly

      by grasping Handle

4    Replace POA-LMP81 Lamp Assembly with a new one and tighten 2 screws

     back. Make sure that POA-LMP81 Lamp Assembly is set properly. Replace

     Lamp Cover and tighten 2 screws

5   Connect AC Power Cord to a projector and turn it on

6    Reset POA-LMP81 Lamp Replace Counter (refer to next page “Lamp Replace

     Counter”section
