60.J6010.CB1 lamp replacement step

Replacing the 60.J6010.CB1 Lamp (Contact your BenQ dealer for assistance)

1. Turn the power off and disconnect the projector from

the wall socket.

2. Use a Phillips screwdriver to loosen the screw (a)

securing the 60.J6010.CB1 lamp cover and then remove the cover

from the projector.

3. Use a Phillips screwdriver to loosen the three screws (b)

securing the 60.J6010.CB1 lamp box.

4. Lift the handle so that it stands up.

5. Use the handle to slowly pull the 60.J6010.CB1 lamp out of the

projector.
